Shopify Integrations with Bit Flows – Automate E-commerce Workflows

Shopify Integrations: The one commerce platform behind it all. Sell online and in person. Sell locally and globally. Sell direct and wholesale. Sell on desktop and mobile.

Bit Flow is a super handy WordPress plugin that helps you connect your favorite tools and automate tasks—without needing to write any code. You can easily link up with over 200 popular apps like Zoho CRM, Google Sheets, WooCommerce, Airtable, Trello, Dropbox, Zoom, HubSpot, Zoho Desk, and many more.

Instead of doing everything manually—like sending data from your forms to your CRM or updating spreadsheets—Bit Flow does it all for you automatically. It saves you time, reduces repetitive work, and keeps everything running smoothly.

In this guide, we’ll show you how to use Shopify as a starting point (called a trigger) to set up your first automation.

Setup Shopify Integrations

First, go to your Bit Flows Dashboard, click on Flows, and then either create a new flow or open an existing one.

After creating or opening an existing flow, you’ll be taken to the Flow Builder screen.

In the Flow Builder, you’ll see a section called Trigger. Under that, click on “Select an App.” A list of trigger apps will appear.

From the list, select your preferred trigger. For this example, click on “Shopify” You’ll then see all the available trigger events.

Now, select your preferred trigger event. For Example: “Order Created“. After selecting your event, you’ll be asked to choose a webhook.

Here, you can either select an existing webhook if you’ve already created one, or create a new one by simply clicking the “Add Webhook” button.

When you click the Add Webhook button, you’ll be prompted to enter a name for your webhook. Simply type in the name and click Save. Another popup will then appear showing the Webhook URL and a Listen Response button.

Now, copy the webhook URL from Bit Flows, then head over to Shopify.

In shopify dashboard, go to the Settings section, search for Webhook.

Create a webhook

Select the event Order Creation

Pest the webhook that you have copied from “bit flow” and save.

For more guidance, check out the video tutorial below.

the next step is to capture the response. To do this, go to the flow builder, click on Listen response and create a order in shopify. After creating the order, return to flow builder and there you will you’ll see that the form data has been successfully captured.

For more guidance, check out the video tutorial below.
